ASTM A182 SS 304 Male Straight Ferrule Union are specialized components made from stainless steel grades 304 and 304L. They connect, cap, or link parts of pipes, tubes, or other fluid-handling systems. The "304" and "304L" refer to the specific alloy composition, with 304L containing a lower carbon content. These fittings are renowned for their resistance to corrosion, mechanical strength, and adaptability to various temperature ranges.
Physical Properties
- Surface Qualities: The lustrous and silvery finish of SS 304/304L Ferrule Fittings is visually appealing and durable over time.
- Heat Transmission: These fittings provide efficient heat transfer properties, ensuring heat is dissipated effectively.
- Mass: With a density of around 8 grams per cubic centimeter, SS 304/304L Ferrule Fittings possess a substantial mass, contributing to their robust nature.
- Magnetic Behavior: Generally non-magnetic, SS 304 can show slight magnetic properties if subjected to cold working processes.
- Resilience: The tensile strength of SS 304 is approximately 515 MPa, demonstrating a robust resistance to pulling forces.
- Flexibility: An admirable yield strength of around 205 MPa in SS 304 and slightly lower in 304L allows these fittings to bend without permanent deformation.
- Welding Convenience: The 304L variant, in particular, offers optimal weldability, as its lower carbon content minimizes the risk of undesirable carbide precipitation during the welding process.
- Rigidity and Pliability: Balancing hardness with ductility, SS 304/304L Ferrule Fittings are crafted to maintain integrity while still being capable of being shaped as needed.
- Elemental Makeup: Comprising 18% chromium and 8% nickel, with traces of other elements, SS 304/304L's composition is finely balanced to deliver optimal performance. The "L" in 304L refers to a reduction in carbon content, typically around 0.03%.
- Resistance to Corrosion: The substantial chromium content equips SS 304/304L Ferrule Fittings with strong defenses against various corrosive agents.
- Stability with Chemicals: In a wide spectrum of chemicals, SS 304/304L Ferrule Fittings exhibit little to no reactivity, a quality ensuring long-term stability.
- Adaptation to Diverse Climates: Whether exposed to freezing temperatures or moderate heat, the properties of SS 304/304L remain consistent, testifying to their adaptability.
Standard: ASTM A182 / ASME SA182
Threads: Unified (SAE) (ASME B 1.1), ISO Parallel - BSPP (BS 2779, ISO 228, JIS B 0202), ISO Tapered - BSPT (BS 21, ISO 7, JIS B 0203), NPT (ASME B1.20.1, MILL-P-71058), ISO / BSP (Gauge) (ISO 228, BS 2779)
Dimensions: ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/16"OD to 2"OD,OD to 50mm OD
Pressure Ratings: High Pressure Tube Fittings, Low Pressure Tube Fittings, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI, 400 Bar.
We also stock & supply : Swagelok Tube Fittings, Parker Fittings, DK LOK Fittings, Hamlet Letlok Fittings, DUOLOK Fittings, GYROLOK Fittings, TYLOK Fittings, BILOK Tube Fittings
ASME SA182 SS 304 Compression Ferrule Fitting
ASME SA182 SS 304 Double Ferrule Tube Fitting
ASTM A182 SS 304 Male Straight Ferrule Union
Din. 1.4301 Double Ferrule Tube Fitting
ASME SA182 SS 304 Compression Ferrule Fitting
Din. 1.4301 Twin Ferrule Fitting
ASTM A182 SS 304 Straight Double Ferrule Fitting
UNS S30400 Compression Hydrulic Ferrule Fitting
ASME SA182 SS 304 Compression Ferrule Fitting
UNS S30400 High Pressure Double Ferrule Tube Fittings
Din. 1.4301 Double Ferrule Tube Fitting
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| SS 304 | S30400 | 1.4301 | Z7CN18‐09 | X5CrNi18-10 | SUS 304 | 304S31 | 08Х18Н10 |
| SS 304L | S30403 | 1.4306 / 1.4307 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 | SUS 304L | 3304S11 | 03Х18Н11 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| 304 | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0-20.0 | - | 8.0-10.5 | 0.10 |
| 304L | 0.035 | 2.0 | 1.0 | 0.045 | 0.03 | 18.0-20.0 | - | 8.0-13 | - |
| Product | Price Per kg |
| ASTM A182 SS 304 Male Straight Ferrule Fitting | ₹ 550/kg |
| Din. 1.4301 Twin Ferrule Fitting | ₹ 510/Kg |
| ASME SA182 SS 304 Compression Ferrule Fitting | ₹ 540/Kg |
| UNS S30400 Compression Hydrulic Ferrule Fitting | ₹ 580/Kg |
Note: All prices mentioned are subject to change due to the volatility of the market. These prices are provided for informational purposes and may fluctuate without prior notice. We advise verifying current prices before making any purchases.
